JCB Clear Water Submersible Pumps are designed to deliver reliable and efficient water transfer in demanding site conditions. Available in two models to suit different hydraulic flow power packs, they provide the flexibility to meet a range of dewatering requirements. Their self-priming design allows for fast setup and immediate operation, helping to maximise productivity on site. A high power-to-weight ratio makes the pumps easy to handle without compromising performance. Being hydraulically driven, they are self-lubricating and require minimal maintenance throughout their service life. The pumps can also run dry without damage, providing added protection during operation.
Flat-face quick-release dripless couplings enable fast and clean attachment changes, reducing downtime between tasks. An integrated lifting eye makes positioning and deployment simple and safe. Each pump is supplied with a 10-metre, 2-inch lay-flat hose for convenient installation and use. Capable of pumping solids in suspension up to 8 mm in diameter, JCB Clear Water Submersible Pumps offer dependable performance across a wide range of water management applications.
| Model name | Submersible Pump | Submersible Pump |
|---|---|---|
| Part number | 929/03900 | 929/04500 |
| Discharge port BSP Male | 50 mm | 50 mm |
| Hyd. flow range | 0 - 22 l/min | 0 - 32 l/min |
| Maximum discharge | 700 l/min | 820 l/min |
| Maximum head | 18 m | 18 m |
| Operating pressure | 138 bar | 138 bar |
| Weight | 8.2 kg | 8.5 kg |
| Width x height | 230 x 302 mm | 230 x 302 mm |
| EHTMA class | C | C |
| Beaver Compatible | Yes | No |
| Trojan Compatible | No | Yes |
